WINDSCREEN WIPER SYSTEM

CAR IDENTIFICATION TR5 - TR6

Before ordering any parts for your TR sports car, it is essential that you have full details of the chassis number, engine number, body number, rear axle and gearbox numbers.

Number Locations

Commission/Chassis Number	The commission number on TR5-250 and early TR6 models were mounted on plates affixed to the top of the inner lefthand front wing. The plate included the commission number which could have a suffix 'L' or 'U' (1971 on) for lefthand drive models, and 'O' for overdrive. Paint & trim colour codes were also shown.
	Later TR6 models had the commission plate attached to the lefthand 'B' post, below the door shut plate.
Body Number	Two plates attached to the bulkhead were body numbers. One was fitted by the manufacturers of the body shell, the other by Triumph. These numbers are not required when ordering replacement parts.
Engine Number	The engine number was stamped onto a lip at the rear of the lefthand side of all engine blocks, just visible below the spark plug. The engine number is essential when ordering engine parts.
Gearbox Number	The gearbox number is stamped onto the casing just behind the clutch lever cross- haft box. On later US models the number was stamped above the starter motor bulge on the righthand side of the gearbox casing. Use this number when ordering gearbox parts.
Rear Axle Number	The rear axle number is located at the base of the axle housing, when viewed from beneath the car. Use this number when ordering axle parts.

TR5 Pi Models
1967	CP1	Prototype
	CP2	First production car, (built 29th August 1967)
	CP585	Last production car that year
1968	CP586	First production car, (built 1st January 1968)
	CP3101	Last production car, (built 19th September 1968)

TR250 Carburettor Models
1967	CD1-L	First production car, (built on 11th July 1967)
	CD2684 L	Last production car that year
1968	CD2685 L	First production car
	CD8594 L	Last production car, (built 19th September 1968)

TR6 Pi Models
1968	1969 model year
	CP25156	First production car, (built 28th November 1968)
	CP25158	Last production car that year
	CP25001	First car was probably a prototype
	CKD	CP25002 To CP25145 were CKD
1969	1969 model year
	CP25159	First production car, (built 2nd January 1969)
	CP26998	Last production car, (built 10th September 1968)
	1970 model year
	CP50001	First production car, (built 1st September 1969)
	CP50464	Last production car that year
	CKD	CP50002 To CP50436 believed to be CKD
1970	1970 model year
	CP50465	First production car, (built 1st January 1970)
	CP52785	Last production car that year
1971	1971 model year
	CP52786	First production car, (built 1st January 1971)
	CP54572	Last production car, (built 7th September 1971)
	CKD	CP54573 To CP54584 were CKD cars
	1972 model year
	CP75001	First production car, (built 27th September 1971)
	CP7544	Last production car that year
1972	1972 model year
	CP75455	First production car, (built 3rd January 1972)
	CP77718	Last production car, (built 21st September 1972)
	1973 model year
	CR169	First production car, (built 15th November 1972)
	CR664	Last production car that year
	CKD	CR1 to CR168 were CKD cars
1973	1973 model year
	CR665	First production car, (built on 2nd January 1973)
	CR2911	Last production car, (built 17th October 1973)
	1974 model year
	CR5049	First production car, (built 14th September 1973)
	CR5612	Last production car that year
	CKD	CR5001 To CR5048 were CKD cars
1974	1974 model year
	CR5613	First production car, (built 1st January 1974)
	CR6630	Last production car that year
1975	1974 model year
	CR6631	First production car, (built 1st January 1975)
	CR6701	Last production car, (built 7th February 1975)

TR6 Carburettor Models
1968	1969 model year
	CC25003 L	First production car, (built 19th September 1968)
	CC27383 L	Last production car that year
	CC25001 & CC25002	Not yet found in factory build records
1969	1969 model year
	CC27384 L	First production car, (built 2nd January 1969)
	CC32142 L	Last production car, (built 19th December 1969)
	1970 model year
	CC50001 L	First production car, (built 22nd November 1969)
	CC51032 L	Last production car that year
1970	1970 model year
	CC51033 L	First production car, (built 1st January 1970)
	CC60902 L	Last production car that year
1971	1971 model year
	CC60903 L	First production car, (built 1st January 1971)
	CC67893 L	Last production car, (built 20th August 1971)
	1972 model year
	CC75001 L	First production car, (built 20th August 1971)
	CC7881	Last production car that year
1972	1972 model year
	CC78813 U	First production car, (built 3rd January 1972)
	CC85737 U	Last production car, (built 5th October 1972)
	1973 model year
	CF1 U	First production car, (built 11th September 1972)
	CF 4028 U	Last production car that year
1973	1973 model year
	CF4029 U	First production car, (built 2nd January 1973)
	CF17002 U	Last production car that year
1974	1974 model year
	CF17002 U	First production car, (built 2nd January 1974)
	CF25777 U	Last production car, (built 18th September 1974)
	1975 model year
	CF27001 U	First production car, (built 22nd August 1974)
	CF29580 U	Last production car that year
1975	1975 model year
	CF29581 U	First production car, (built 2nd January 1975)
	CF39991 U	Last production car, (built 23rd August 1975)
	1976 model year
	CF50001 U	First production car, (built 29th August 1975)
	CF52314 U	Last production car that year
1976	1976 model year
	CF52315 U	First production car, (built 5th January 1976)
	CF58328 U	Last production TR6, (built 15th July 1976)

Ill.no.	Partno.	Part	Quantity required	Info	Price
1	514821	WIPER MOTOR ASS	1	TR5 and TR250	availability request (add quantity to basket, offer follows)
1	514821R	WIPER MOTOR COU	1	TR5 and TR250	availability request (add quantity to basket, offer follows)

Ill.no.	Partno.	Part	Quantity required	Info	Price
2	511094	COVER END W/MOTOR	1	TR5 and TR250	availability request (add quantity to basket, offer follows)

Ill.no.	Partno.	Part	Quantity required	Info	Price
3	511001	BOLT W/MOTOR	2	TR5 and TR250	availability request (add quantity to basket, offer follows)

Ill.no.	Partno.	Part	Quantity required	Info	Price
4	508169	USE 508170	1	TR5 and TR250
4	508170	BRUSH SET WIPER MOTOR DR1-3	1	TR5 and TR250	CHF 17.80

Ill.no.	Partno.	Part	Quantity required	Info	Price
5	508170	BRUSH SET WIPER MOTOR DR1-3	1	TR5 and TR250	CHF 17.80

Ill.no.	Partno.	Part	Quantity required	Info	Price
6	057492	USE 508170	1	TR5 and TR250
6	508170	BRUSH SET WIPER MOTOR DR1-3	1	TR5 and TR250	CHF 17.80

Ill.no.	Partno.	Part	Quantity required	Info	Price
7	511095	COIL FIELD W/MOTOR 2SPD	1	TR5 and TR250	availability request (add quantity to basket, offer follows)

Ill.no.	Partno.	Part	Quantity required	Info	Price
8	511003	ARMATURE WIPER MOTOR	1	TR5 and TR250	availability request (add quantity to basket, offer follows)

Ill.no.	Partno.	Part	Quantity required	Info	Price
9	511006	USE 57H5559	1	TR5 and TR250
9	57H5559	PARK SWITCH & COVER	1	TR5 and TR250	availability request (add quantity to basket, offer follows)

Ill.no.	Partno.	Part	Quantity required	Info	Price
10	511096	LINK ROD	1	TR5 and TR250	availability request (add quantity to basket, offer follows)

Ill.no.	Partno.	Part	Quantity required	Info	Price
11	511078	WIPER MOTOR GEAR WITH AXLE, 120°	1	TR5 and TR250	availability request (add quantity to basket, offer follows)
11	505869	USE 520939	1	TR5 and TR250
11	520939	GEARBOX WIPER MOTOR	1	TR5 and TR250	availability request (add quantity to basket, offer follows)

Ill.no.	Partno.	Part	Quantity required	Info	Price
12	17H5431	MOUNTING KIT WIPER MOTOR	3	TR5 and TR250	CHF 7.95

Ill.no.	Partno.	Part	Quantity required	Info	Price
13	17H5431X	USE 17H5431	3	TR5 and TR250
13	17H5431	MOUNTING KIT WIPER MOTOR	3	TR5 and TR250	CHF 7.95

Ill.no.	Partno.	Part	Quantity required	Info	Price
14	611169	WIPER MOTOR MOUNT PLATE TR4A-5	3	TR5 and TR250	availability request (add quantity to basket, offer follows)

Ill.no.	Partno.	Part	Quantity required	Info	Price
15	GHF101	SCREW 1/4 UNF X 1IN	2	TR5 and TR250	CHF 0.65

Ill.no.	Partno.	Part	Quantity required	Info	Price
16	GHF331	WASHER SPRING 1/4"	2	TR5 and TR250	CHF 0.55

Ill.no.	Partno.	Part	Quantity required	Info	Price
17	WM57	WASHER, PLAIN, 1/4" ID X 3/4" OD	2	TR5 and TR250	CHF 0.65

Ill.no.	Partno.	Part	Quantity required	Info	Price
18	SH604041	SCREW 1/4" UNF X 1/2"	1	TR5 and TR250	CHF 0.55

Ill.no.	Partno.	Part	Quantity required	Info	Price
19	GHF331	WASHER SPRING 1/4"	1	TR5 and TR250	CHF 0.55

Ill.no.	Partno.	Part	Quantity required	Info	Price
20	WM57	WASHER, PLAIN, 1/4" ID X 3/4" OD	1	TR5 and TR250	CHF 0.65

Ill.no.	Partno.	Part	Quantity required	Info	Price
21	RTC202A	RACK WIPER CUT TO FIT	1	TR5 and TR250 - cut to 28 13/32"	CHF 39.05

Ill.no.	Partno.	Part	Quantity required	Info	Price
22	37H5282	CONNECTING PIECE WIPER STRING TO MOTOR (FERRULE)	1	TR5 and TR250	CHF 27.70

Ill.no.	Partno.	Part	Quantity required	Info	Price
23	AAU1909A	WIPER RACK TUBE	1	TR5 and TR250 - Motor to first wheelbox	CHF 44.15

Ill.no.	Partno.	Part	Quantity required	Info	Price
24	131151	USE AAU1909A	1	TR5 and TR250
24	AAU1909A	WIPER RACK TUBE	1	TR5 and TR250	CHF 44.15

Ill.no.	Partno.	Part	Quantity required	Info	Price
25	575047A	RACK TUBING, WHEELBOX END WIPER SYSTEM	1	TR5 and TR250	CHF 13.70

Ill.no.	Partno.	Part	Quantity required	Info	Price
26	AAU1909A	WIPER RACK TUBE	a/r	TR5 and TR250	CHF 44.15

Ill.no.	Partno.	Part	Quantity required	Info	Price
27	600395	GROMMET, RUBBER, 1"OD X 1/8"ID	1	TR5 and TR250	CHF 2.70

Ill.no.	Partno.	Part	Quantity required	Info	Price
28	37H6316	WHEELBOX WINDSCREEN WIPER	2	TR5 and TR250	CHF 55.35

Ill.no.	Partno.	Part	Quantity required	Info	Price
29	ANK3459	CHROME NUT WIPER BASE	2	TR5 and TR250	CHF 3.35

Ill.no.	Partno.	Part	Quantity required	Info	Price
30	LU54704807	WASHER JET AND BUSH KIT	1	TR5 and TR250	CHF 77.75

Ill.no.	Partno.	Part	Quantity required	Info	Price
31	511071	JET & BUSH UPPER, LH	1	TR5 and TR250	CHF 19.05

Ill.no.	Partno.	Part	Quantity required	Info	Price
32	511070	JET & BUSH UPPER, RH	1	TR5 and TR250	CHF 21.00

Ill.no.	Partno.	Part	Quantity required	Info	Price
33	112740	JET FOR 511070/1	2	TR5 and TR250	availability request (add quantity to basket, offer follows)

Ill.no.	Partno.	Part	Quantity required	Info	Price
34	37H4952	WIPER ARM, STRAIGHT, DRIVERS SIDE, RHD	1	TR5, RHD, bright finish	CHF 43.40

Ill.no.	Partno.	Part	Quantity required	Info	Price
35	131106	WISHER ARM RHD LH ARM	1	TR5, RHD, bright finish	CHF 40.10

Ill.no.	Partno.	Part	Quantity required	Info	Price
36	GWB219	WIPER BLADE, 10",5,2MM, BRIGHT	2	TR5, RHD, bright finish	CHF 17.95
36	GWB219BLACK	WIPER BLADE, 10", 5,2MM, BLACK, BAYONET, AFTERMARKET	2	TR5, RHD, schwarz	availability request (add quantity to basket, offer follows)

Ill.no.	Partno.	Part	Quantity required	Info	Price
36	GWB219	WIPER BLADE, 10",5,2MM, BRIGHT	2	TR5, RHD, bright finish	CHF 17.95
36	GWB219BLACK	WIPER BLADE, 10", 5,2MM, BLACK, BAYONET, AFTERMARKET	2	TR5, RHD, black	availability request (add quantity to basket, offer follows)

Ill.no.	Partno.	Part	Quantity required	Info	Price
37	131108	WIPER ARM LH LHD	1	TR5, TR250 LHD, bright finish	CHF 60.45

Ill.no.	Partno.	Part	Quantity required	Info	Price
38	131107	WIPER ARM LHD RH	1	TR5, TR250 LHD, bright finish	CHF 60.45

Ill.no.	Partno.	Part	Quantity required	Info	Price
39	GWB219	WIPER BLADE, 10",5,2MM, BRIGHT	2	TR5, TR250 LHD, bright finish	CHF 17.95
39	GWB219BLACK	WIPER BLADE, 10", 5,2MM, BLACK, BAYONET, AFTERMARKET	2	TR5, TR250 LHD, black	availability request (add quantity to basket, offer follows)

Ill.no.	Partno.	Part	Quantity required	Info	Price
39	GWB219	WIPER BLADE, 10",5,2MM, BRIGHT	2	TR5, TR250 LHD, bright finish	CHF 17.95
39	GWB219BLACK	WIPER BLADE, 10", 5,2MM, BLACK, BAYONET, AFTERMARKET	2	TR5, TR250 LHD, black	availability request (add quantity to basket, offer follows)

Ill.no.	Partno.	Part	Quantity required	Info	Price
40	GWR120	WIPER BLADE REFILL, RUBBER, BLACK, PAIR	1	TR5 and TR250	availability request (add quantity to basket, offer follows)

Ill.no.	Partno.	Part	Quantity required	Info	Price
41	148410	USE 13H7761	1	TR5 and TR250
41	13H7761	TOGGLE SWITCH WIPER, 2-STAGE, WITH CHROME FRAME, 4 CONNECTIONS	1	TR5 and TR250	CHF 94.55

Ill.no.	Partno.	Part	Quantity required	Info	Price
42	158452	SWITCH, ROCKER, WINDSCREEN WASHERS	1	TR5 and TR250	CHF 95.60

Ill.no.	Partno.	Part	Quantity required	Info	Price
43	GXE7708	WIPER MOTOR 14W, NO GEAR, 2 SPEED	1	TR6	CHF 97.10

Ill.no.	Partno.	Part	Quantity required	Info	Price
44	517643	USE 37H8222	1	TR6

Ill.no.	Partno.	Part	Quantity required	Info	Price
45	RTC198A	BRUSH SET WIPER	1	TR6 - Lucas nos. 75664A, 75664B, 75664D & 75664F	CHF 37.55

Ill.no.	Partno.	Part	Quantity required	Info	Price
46	517645	WIPER MOTOR LIMIT SWITCH WITH 3 CABLES	1	TR6 - Lucas nos. 75664A & 75664B	availability request (add quantity to basket, offer follows)
46	520160A	SWITCH, PARKING CLIP FITTING	1	TR6 - Lucas nos. 75664D & 75664F	CHF 28.05

Ill.no.	Partno.	Part	Quantity required	Info	Price
47	37H3048	WIPER MOTOR GEARBOX/GEAR 115°	1	TR6	CHF 48.80

Ill.no.	Partno.	Part	Quantity required	Info	Price
48	150846K	MOUNTING KIT WIPERMOTOR	1	TR6	CHF 17.90

Ill.no.	Partno.	Part	Quantity required	Info	Price
49	150844A	PAD, WIPER MOTOR	1	TR6	CHF 4.05

Ill.no.	Partno.	Part	Quantity required	Info	Price
50	BHA4790	WIPER MOTOR RETAINING BRACKET	1	TR6	CHF 12.95

Ill.no.	Partno.	Part	Quantity required	Info	Price
52	SH604041	SCREW 1/4" UNF X 1/2"	2	TR6	CHF 0.55

Ill.no.	Partno.	Part	Quantity required	Info	Price
53	GHF331	WASHER SPRING 1/4"	2	TR6	CHF 0.55

Ill.no.	Partno.	Part	Quantity required	Info	Price
54	GHF300	WASHER 1/4 X 1/2 OD	2	TR6	CHF 0.25

Ill.no.	Partno.	Part	Quantity required	Info	Price
55	RTC202A	RACK WIPER CUT TO FIT	1	TR6 - cut to 28 13/32"	CHF 39.05

Ill.no.	Partno.	Part	Quantity required	Info	Price
56	37H3694	CONNECTING PIECE WIPER STRING TO MOTOR (FERRULE)	1	TR6	CHF 3.60

Ill.no.	Partno.	Part	Quantity required	Info	Price
57	625614	USE AAU1909A	1	TR6 - Motor to first wheelbox
57	AAU1909A	WIPER RACK TUBE	1	TR6 - Motor to first wheelbox	CHF 44.15

Ill.no.	Partno.	Part	Quantity required	Info	Price
58	625613	USE AAU1909A	1	TR6
58	AAU1909A	WIPER RACK TUBE	1	TR6	CHF 44.15

Ill.no.	Partno.	Part	Quantity required	Info	Price
59	575047A	RACK TUBING, WHEELBOX END WIPER SYSTEM	1	TR6	CHF 13.70

Ill.no.	Partno.	Part	Quantity required	Info	Price
60	AAU1909A	WIPER RACK TUBE	a/r	TR6 - must be cut to length and flared	CHF 44.15

Ill.no.	Partno.	Part	Quantity required	Info	Price
61	600395	GROMMET, RUBBER, 1"OD X 1/8"ID	1	TR6	CHF 2.70

Ill.no.	Partno.	Part	Quantity required	Info	Price
62	37H7738	WIPER WHEEL BOX	2		CHF 36.90

Ill.no.	Partno.	Part	Quantity required	Info	Price
63	17H8769	CHROME NUT WIPER BASE	2	TR6	CHF 3.35

Ill.no.	Partno.	Part	Quantity required	Info	Price
64	LU54704807	WASHER JET AND BUSH KIT	1	TR6	CHF 77.75

Ill.no.	Partno.	Part	Quantity required	Info	Price
65	511071	JET & BUSH UPPER, LH	1	TR6	CHF 19.05

Ill.no.	Partno.	Part	Quantity required	Info	Price
66	511070	JET & BUSH UPPER, RH	1	TR6	CHF 21.00

Ill.no.	Partno.	Part	Quantity required	Info	Price
67	112740	JET FOR 511070/1	2	TR6	availability request (add quantity to basket, offer follows)

Ill.no.	Partno.	Part	Quantity required	Info	Price
68	151886Z	WIPER ARM, BRIGHT, STRAIGHT FITTING, DRIVERS SIDE, RHD, AFTERMARKET	1	TR6 To CR1, RHD, bright finish	CHF 40.10
68	BHA5205Z	WIPER ARM, BLACK, STRAIGHT FITTING, DRIVERS SIDE, RHD	1	TR6 From CR1, RHD, black finish	CHF 37.80

Ill.no.	Partno.	Part	Quantity required	Info	Price
69	151888Z	WIPER ARM, CHROME, CRANKED, PASSENGER SIDE, RHD, AFTERMARKET	1	TR6 To CR1, RHD, bright finish	CHF 40.10
69	159686Z	WIPER ARM, BLACK, CRANKED, PASSENGER SIDE, RHD, AFTERMARKET	1	TR6 From CR1, RHD, black finish	CHF 46.75

Ill.no.	Partno.	Part	Quantity required	Info	Price
70	GWB118Z	WIPER BLADE 11", 7,2MM, BAYONET, STAINLESS STEEL	2	TR6 To CR1, RHD, bright finish	CHF 18.50
70	GWB180Z	WIPER BLADE 11", 7,2MM, BAYONET, ORIGINAL TYPE, BLACK	2	TR6 From CR1, RHD, black finish - original fitting	CHF 23.75

Ill.no.	Partno.	Part	Quantity required	Info	Price
70	GWB118Z	WIPER BLADE 11", 7,2MM, BAYONET, STAINLESS STEEL	2	TR6 To CR1, RHD, bright finish	CHF 18.50
70	GWB180Z	WIPER BLADE 11", 7,2MM, BAYONET, ORIGINAL TYPE, BLACK	2	TR6 From CR1, RHD, black finish - original fitting	CHF 23.75

Ill.no.	Partno.	Part	Quantity required	Info	Price
71	151887Z	WIPER ARM, BRIGHT, STRAIGHT FITTING, DRIVERS SIDE, LHD, AFTERMARKET	1	TR6 To CR1/CF1, LHD, bright finish	CHF 40.10
71	159684Z	WIPER ARM, STRAIGHT, DRIVERS SIDE, LHD, AFTERMARKET	1	TR6 From CR1/CF1, LHD, black finish	CHF 44.00

Ill.no.	Partno.	Part	Quantity required	Info	Price
72	151885Z	WIPER ARM, CHROME, CRANKED, PASSENGER SIDE, LHD, AFTERMARKET	1	TR6 To CR1/CF1, LHD, bright finish	CHF 40.10
72	159685Z	WIPER ARM, BLACK, CRANKED, PASSENGER SIDE, LHD, AFTERMARKET	1	TR6 From CR1/CF1, LHD, black finish	CHF 44.00

Ill.no.	Partno.	Part	Quantity required	Info	Price
73	GWB118Z	WIPER BLADE 11", 7,2MM, BAYONET, STAINLESS STEEL	2	TR6 To CR1/CF1, LHD, bright finish	CHF 18.50
73	GWB180Z	WIPER BLADE 11", 7,2MM, BAYONET, ORIGINAL TYPE, BLACK	2	TR6 From CR1/CF1, LHD, black finish - original fitting	CHF 23.75

Ill.no.	Partno.	Part	Quantity required	Info	Price
73	GWB118Z	WIPER BLADE 11", 7,2MM, BAYONET, STAINLESS STEEL	2	TR6 To CR1/CF1, LHD, bright finish	CHF 18.50
73	GWB180Z	WIPER BLADE 11", 7,2MM, BAYONET, ORIGINAL TYPE, BLACK	2	TR6 From CR1/CF1, LHD, black finish - original fitting	CHF 23.75

Ill.no.	Partno.	Part	Quantity required	Info	Price
74	GWR120	WIPER BLADE REFILL, RUBBER, BLACK, PAIR	1		availability request (add quantity to basket, offer follows)

Ill.no.	Partno.	Part	Quantity required	Info	Price
75	13H7761	TOGGLE SWITCH WIPER, 2-STAGE, WITH CHROME FRAME, 4 CONNECTIONS	1		CHF 94.55

Ill.no.	Partno.	Part	Quantity required	Info	Price
76	158452	SWITCH, ROCKER, WINDSCREEN WASHERS	1	TR6	CHF 95.60

Ill.no.	Partno.	Part	Quantity required	Info	Price
77	155496	USE 155496Z	1	TR6 from CR1/CF1 - Clear-hooter
77	155496Z	WIPER/WASHER SWITCH ASSEMBLY, REPRODUCTION	1	TR6 from CR1/CF1 - Lucas replacement	CHF 116.30

Ill.no.	Partno.	Part	Quantity required	Info	Price
78	621510	SPACER TUBE	1	TR6 from CR1/CF1	availability request (add quantity to basket, offer follows)

Ill.no.	Partno.	Part	Quantity required	Info	Price
79	622682	ROUND NUT WASHING PUMP/SWITCH	1	TR6 from CR1/CF1	availability request (add quantity to basket, offer follows)

Ill.no.	Partno.	Part	Quantity required	Info	Price
80	616048	WASHER PVC - NCA-	1	TR6 from CR1/CF1	availability request (add quantity to basket, offer follows)

Ill.no.	Partno.	Part	Quantity required	Info	Price
81	622443	SCREW ROSETTE IN SPACER SLEEVE WASHING PUMP	1	TR6 from CR1/CF1	availability request (add quantity to basket, offer follows)

Ill.no.	Partno.	Part	Quantity required	Info	Price
82	059445	PAD, RUBBER	1	TR6 from CR1/CF1	availability request (add quantity to basket, offer follows)

Ill.no.	Partno.	Part	Quantity required	Info	Price
83	725374	CONTROL KNOB WIPER/WASHER SWITCH, ANGULAR WITH SYMBOLS	1	TR6 from CR1/CF1	CHF 15.85

Ill.no.	Partno.	Part	Quantity required	Info	Price
85	GXE7708P	PLUG & LEAD, WIPER MOTOR WIRING	a/r	TR6 from CR1/CF1	CHF 31.55

Ill.no.	Partno.	Part	Quantity required	Info	Price
1	514821	WIPER MOTOR ASS	1	TR5 and TR250	availability request (add quantity to basket, offer follows)
1	514821R	WIPER MOTOR COU	1	TR5 and TR250	availability request (add quantity to basket, offer follows)
2	511094	COVER END W/MOTOR	1	TR5 and TR250	availability request (add quantity to basket, offer follows)
3	511001	BOLT W/MOTOR	2	TR5 and TR250	availability request (add quantity to basket, offer follows)
4	508169	USE 508170	1	TR5 and TR250
4	508170	BRUSH SET WIPER MOTOR DR1-3	1	TR5 and TR250	CHF 17.80
5	508170	BRUSH SET WIPER MOTOR DR1-3	1	TR5 and TR250	CHF 17.80
6	057492	USE 508170	1	TR5 and TR250
6	508170	BRUSH SET WIPER MOTOR DR1-3	1	TR5 and TR250	CHF 17.80
7	511095	COIL FIELD W/MOTOR 2SPD	1	TR5 and TR250	availability request (add quantity to basket, offer follows)
8	511003	ARMATURE WIPER MOTOR	1	TR5 and TR250	availability request (add quantity to basket, offer follows)
9	511006	USE 57H5559	1	TR5 and TR250
9	57H5559	PARK SWITCH & COVER	1	TR5 and TR250	availability request (add quantity to basket, offer follows)
10	511096	LINK ROD	1	TR5 and TR250	availability request (add quantity to basket, offer follows)
11	511078	WIPER MOTOR GEAR WITH AXLE, 120°	1	TR5 and TR250	availability request (add quantity to basket, offer follows)
11	505869	USE 520939	1	TR5 and TR250
11	520939	GEARBOX WIPER MOTOR	1	TR5 and TR250	availability request (add quantity to basket, offer follows)
12	17H5431	MOUNTING KIT WIPER MOTOR	3	TR5 and TR250	CHF 7.95
13	17H5431X	USE 17H5431	3	TR5 and TR250
13	17H5431	MOUNTING KIT WIPER MOTOR	3	TR5 and TR250	CHF 7.95
14	611169	WIPER MOTOR MOUNT PLATE TR4A-5	3	TR5 and TR250	availability request (add quantity to basket, offer follows)
15	GHF101	SCREW 1/4 UNF X 1IN	2	TR5 and TR250	CHF 0.65
16	GHF331	WASHER SPRING 1/4"	2	TR5 and TR250	CHF 0.55
17	WM57	WASHER, PLAIN, 1/4" ID X 3/4" OD	2	TR5 and TR250	CHF 0.65
18	SH604041	SCREW 1/4" UNF X 1/2"	1	TR5 and TR250	CHF 0.55
19	GHF331	WASHER SPRING 1/4"	1	TR5 and TR250	CHF 0.55
20	WM57	WASHER, PLAIN, 1/4" ID X 3/4" OD	1	TR5 and TR250	CHF 0.65
21	RTC202A	RACK WIPER CUT TO FIT	1	TR5 and TR250 - cut to 28 13/32"	CHF 39.05
22	37H5282	CONNECTING PIECE WIPER STRING TO MOTOR (FERRULE)	1	TR5 and TR250	CHF 27.70
23	AAU1909A	WIPER RACK TUBE	1	TR5 and TR250 - Motor to first wheelbox	CHF 44.15
24	131151	USE AAU1909A	1	TR5 and TR250
24	AAU1909A	WIPER RACK TUBE	1	TR5 and TR250	CHF 44.15
25	575047A	RACK TUBING, WHEELBOX END WIPER SYSTEM	1	TR5 and TR250	CHF 13.70
26	AAU1909A	WIPER RACK TUBE	a/r	TR5 and TR250	CHF 44.15
27	600395	GROMMET, RUBBER, 1"OD X 1/8"ID	1	TR5 and TR250	CHF 2.70
28	37H6316	WHEELBOX WINDSCREEN WIPER	2	TR5 and TR250	CHF 55.35
29	ANK3459	CHROME NUT WIPER BASE	2	TR5 and TR250	CHF 3.35
30	LU54704807	WASHER JET AND BUSH KIT	1	TR5 and TR250	CHF 77.75
31	511071	JET & BUSH UPPER, LH	1	TR5 and TR250	CHF 19.05
32	511070	JET & BUSH UPPER, RH	1	TR5 and TR250	CHF 21.00
33	112740	JET FOR 511070/1	2	TR5 and TR250	availability request (add quantity to basket, offer follows)
34	37H4952	WIPER ARM, STRAIGHT, DRIVERS SIDE, RHD	1	TR5, RHD, bright finish	CHF 43.40
35	131106	WISHER ARM RHD LH ARM	1	TR5, RHD, bright finish	CHF 40.10
36	GWB219	WIPER BLADE, 10",5,2MM, BRIGHT	2	TR5, RHD, bright finish	CHF 17.95
36	GWB219BLACK	WIPER BLADE, 10", 5,2MM, BLACK, BAYONET, AFTERMARKET	2	TR5, RHD, schwarz	availability request (add quantity to basket, offer follows)
37	131108	WIPER ARM LH LHD	1	TR5, TR250 LHD, bright finish	CHF 60.45
38	131107	WIPER ARM LHD RH	1	TR5, TR250 LHD, bright finish	CHF 60.45
39	GWB219	WIPER BLADE, 10",5,2MM, BRIGHT	2	TR5, TR250 LHD, bright finish	CHF 17.95
39	GWB219BLACK	WIPER BLADE, 10", 5,2MM, BLACK, BAYONET, AFTERMARKET	2	TR5, TR250 LHD, black	availability request (add quantity to basket, offer follows)
40	GWR120	WIPER BLADE REFILL, RUBBER, BLACK, PAIR	1	TR5 and TR250	availability request (add quantity to basket, offer follows)
41	148410	USE 13H7761	1	TR5 and TR250
41	13H7761	TOGGLE SWITCH WIPER, 2-STAGE, WITH CHROME FRAME, 4 CONNECTIONS	1	TR5 and TR250	CHF 94.55
42	158452	SWITCH, ROCKER, WINDSCREEN WASHERS	1	TR5 and TR250	CHF 95.60
43	GXE7708	WIPER MOTOR 14W, NO GEAR, 2 SPEED	1	TR6	CHF 97.10
44	517643	USE 37H8222	1	TR6
45	RTC198A	BRUSH SET WIPER	1	TR6 - Lucas nos. 75664A, 75664B, 75664D & 75664F	CHF 37.55
46	517645	WIPER MOTOR LIMIT SWITCH WITH 3 CABLES	1	TR6 - Lucas nos. 75664A & 75664B	availability request (add quantity to basket, offer follows)
46	520160A	SWITCH, PARKING CLIP FITTING	1	TR6 - Lucas nos. 75664D & 75664F	CHF 28.05
47	37H3048	WIPER MOTOR GEARBOX/GEAR 115°	1	TR6	CHF 48.80
48	150846K	MOUNTING KIT WIPERMOTOR	1	TR6	CHF 17.90
49	150844A	PAD, WIPER MOTOR	1	TR6	CHF 4.05
50	BHA4790	WIPER MOTOR RETAINING BRACKET	1	TR6	CHF 12.95
52	SH604041	SCREW 1/4" UNF X 1/2"	2	TR6	CHF 0.55
53	GHF331	WASHER SPRING 1/4"	2	TR6	CHF 0.55
54	GHF300	WASHER 1/4 X 1/2 OD	2	TR6	CHF 0.25
55	RTC202A	RACK WIPER CUT TO FIT	1	TR6 - cut to 28 13/32"	CHF 39.05
56	37H3694	CONNECTING PIECE WIPER STRING TO MOTOR (FERRULE)	1	TR6	CHF 3.60
57	625614	USE AAU1909A	1	TR6 - Motor to first wheelbox
57	AAU1909A	WIPER RACK TUBE	1	TR6 - Motor to first wheelbox	CHF 44.15
58	625613	USE AAU1909A	1	TR6
58	AAU1909A	WIPER RACK TUBE	1	TR6	CHF 44.15
59	575047A	RACK TUBING, WHEELBOX END WIPER SYSTEM	1	TR6	CHF 13.70
60	AAU1909A	WIPER RACK TUBE	a/r	TR6 - must be cut to length and flared	CHF 44.15
61	600395	GROMMET, RUBBER, 1"OD X 1/8"ID	1	TR6	CHF 2.70
62	37H7738	WIPER WHEEL BOX	2		CHF 36.90
63	17H8769	CHROME NUT WIPER BASE	2	TR6	CHF 3.35
64	LU54704807	WASHER JET AND BUSH KIT	1	TR6	CHF 77.75
65	511071	JET & BUSH UPPER, LH	1	TR6	CHF 19.05
66	511070	JET & BUSH UPPER, RH	1	TR6	CHF 21.00
67	112740	JET FOR 511070/1	2	TR6	availability request (add quantity to basket, offer follows)
68	151886Z	WIPER ARM, BRIGHT, STRAIGHT FITTING, DRIVERS SIDE, RHD, AFTERMARKET	1	TR6 To CR1, RHD, bright finish	CHF 40.10
68	BHA5205Z	WIPER ARM, BLACK, STRAIGHT FITTING, DRIVERS SIDE, RHD	1	TR6 From CR1, RHD, black finish	CHF 37.80
69	151888Z	WIPER ARM, CHROME, CRANKED, PASSENGER SIDE, RHD, AFTERMARKET	1	TR6 To CR1, RHD, bright finish	CHF 40.10
69	159686Z	WIPER ARM, BLACK, CRANKED, PASSENGER SIDE, RHD, AFTERMARKET	1	TR6 From CR1, RHD, black finish	CHF 46.75
70	GWB118Z	WIPER BLADE 11", 7,2MM, BAYONET, STAINLESS STEEL	2	TR6 To CR1, RHD, bright finish	CHF 18.50
70	GWB180Z	WIPER BLADE 11", 7,2MM, BAYONET, ORIGINAL TYPE, BLACK	2	TR6 From CR1, RHD, black finish - original fitting	CHF 23.75
71	151887Z	WIPER ARM, BRIGHT, STRAIGHT FITTING, DRIVERS SIDE, LHD, AFTERMARKET	1	TR6 To CR1/CF1, LHD, bright finish	CHF 40.10
71	159684Z	WIPER ARM, STRAIGHT, DRIVERS SIDE, LHD, AFTERMARKET	1	TR6 From CR1/CF1, LHD, black finish	CHF 44.00
72	151885Z	WIPER ARM, CHROME, CRANKED, PASSENGER SIDE, LHD, AFTERMARKET	1	TR6 To CR1/CF1, LHD, bright finish	CHF 40.10
72	159685Z	WIPER ARM, BLACK, CRANKED, PASSENGER SIDE, LHD, AFTERMARKET	1	TR6 From CR1/CF1, LHD, black finish	CHF 44.00
73	GWB118Z	WIPER BLADE 11", 7,2MM, BAYONET, STAINLESS STEEL	2	TR6 To CR1/CF1, LHD, bright finish	CHF 18.50
73	GWB180Z	WIPER BLADE 11", 7,2MM, BAYONET, ORIGINAL TYPE, BLACK	2	TR6 From CR1/CF1, LHD, black finish - original fitting	CHF 23.75
74	GWR120	WIPER BLADE REFILL, RUBBER, BLACK, PAIR	1		availability request (add quantity to basket, offer follows)
75	13H7761	TOGGLE SWITCH WIPER, 2-STAGE, WITH CHROME FRAME, 4 CONNECTIONS	1		CHF 94.55
76	158452	SWITCH, ROCKER, WINDSCREEN WASHERS	1	TR6	CHF 95.60
77	155496	USE 155496Z	1	TR6 from CR1/CF1 - Clear-hooter
77	155496Z	WIPER/WASHER SWITCH ASSEMBLY, REPRODUCTION	1	TR6 from CR1/CF1 - Lucas replacement	CHF 116.30
78	621510	SPACER TUBE	1	TR6 from CR1/CF1	availability request (add quantity to basket, offer follows)
79	622682	ROUND NUT WASHING PUMP/SWITCH	1	TR6 from CR1/CF1	availability request (add quantity to basket, offer follows)
80	616048	WASHER PVC - NCA-	1	TR6 from CR1/CF1	availability request (add quantity to basket, offer follows)
81	622443	SCREW ROSETTE IN SPACER SLEEVE WASHING PUMP	1	TR6 from CR1/CF1	availability request (add quantity to basket, offer follows)
82	059445	PAD, RUBBER	1	TR6 from CR1/CF1	availability request (add quantity to basket, offer follows)
83	725374	CONTROL KNOB WIPER/WASHER SWITCH, ANGULAR WITH SYMBOLS	1	TR6 from CR1/CF1	CHF 15.85
85	GXE7708P	PLUG & LEAD, WIPER MOTOR WIRING	a/r	TR6 from CR1/CF1	CHF 31.55
